New Reduced price! VC12RN924 24VAC/DC View larger

VC12RN230 230VAC

VC12RN230

New product

Capacitive sensor is typically used as empty, full and level indicator in tanks, silos and containers for example with: grain, feed. The powerful integrated relay means that it can control many functions directly. The VC12RN230 is easily mounted in a plastic gland PG-36.

A capacitive level sensor with relay output 2A 240VAC. Power supply: 230VAC. Diameter: 32mm.

More details

88,35 € tax excl.

-5%

93,00 € tax excl.

Add to wishlist

More info

Datasheet VC12RN

Datenblatt VC12RN

User manual VC12RN

Capacitive sensor in thermoplastic polyester for mounting in PG-36 screw gland. Adjustable sensing distance: 4-12mm.

VC12RN230 capacitive sensor is typically used as empty, full and level indicator in tanks, silos and containers for example with: grain, feed. The integrated relay means that it can control many functions directly.

Rated opertional voltage: 230 VAC; 47-63 Hz
Consumption: 1,5 W
Sensing distance: 4 - 12 mm (adjustable)
Hysteresis: 1,5 mm at 7 mm sensing distance
Operatin frequency: 1 Hz
Output: relay 2A / 240 VAC
Indication for output ON: LED red
Degree of protection: IP67
Operation temperature: -20°C do + 70°C
Cabel: 2m, PVC
